| Standards and Protocols | | IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP | | Basic Function | | Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode | | Backbound Bandwidth | | 4.8Gbps | | MAC Address Table | | 8k | | Forwarding Rate | | 10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port | | Transmission Method | | Store-and-Forward | | Ports | | 24 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) | | Network Media | | 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m) | | Dimensions (W*D*H) | | 17.3*7.1*1.7 in. (440*180*44 mm) | | | | |
|
